Davies Craig EWP180

The EWP®180 is engineered for serious cooling performance where flow under pressure matters. While the EWP®180 delivers an impressive 180 L/min open flow, the true measure of performance is its ability to maintain strong circulation under load: 93 L/min @ 1.5 Bar (15m Head)

The EWP^®180 – 12V Brushless Electric Water Pump is engineered for extreme cooling performance where flow under pressure truly matters.

While many pumps advertise peak open flow numbers, real-world systems operate under restriction — through radiators, intercooler cores, heat exchangers and long plumbing runs.

93 L/min @ 1.5 Bar (15m Head)

This is the number that defines the EWP^®180.

Delivering a massive 93 litres per minute at 1.5 bar, the EWP^®180 provides genuine, usable flow in pressurised cooling systems — making it an ideal solution for:

• High-boost turbo and supercharged engines

• Water-to-air intercooler systems

• Charge cooler circuits

• Motorsport endurance applications

• Rear-mounted radiator setups

• Marine and heavy-duty cooling systems

With advanced magnetic drive brushless motor technology, IP68 sealing and full PWM control compatibility, this pump provides precise, reliable cooling performance in the harshest environments.

Engineered for Long Life – Brushless Magnetic Drive Motor

At the heart of the EWP^®180 is a magnetic drive brushless motor, specifically chosen for durability, efficiency and continuous-duty operation.

Unlike traditional brushed electric water pumps that rely on carbon brushes (which wear over time), the EWP^®180’s brushless design eliminates brush contact — significantly reducing mechanical wear and extending operational lifespan.

Why Brushless Matters

✔ No carbon brushes to wear out
✔ Reduced internal friction
✔ Lower heat generation
✔ Improved electrical efficiency
✔ Greater reliability in continuous operation
✔ Designed for sustained high-load cooling systems

For intercooler pump and charge cooler applications, where the pump may run continuously during boost or extended track sessions, long-term durability is critical. The brushless motor ensures stable performance even in high-temperature engine bays and demanding motorsport environments.

Advanced Brushless Motor Technology

Unlike conventional brushed electric water pumps, the EWP^®180 uses a magnetic drive brushless motor, delivering:

• Longer service life
• Reduced electrical noise
• Greater efficiency
• Improved reliability in continuous duty intercooler circuits
• Stable flow in high-temperature engine bays

Full PWM control (100–1000 Hz) allows integration with modern ECUs and standalone controllers, enabling intelligent temperature-based flow management for both engine cooling and intercooler systems.

For optimum coolant management, Davies, Craig recommends the installation of Brushless Variable Speed Fan and EWP^® Controller (Part #0550 or #0551).

Davies, Craig has a full range of Digital Thermatic^® Fan Switches for when on/off control of the EWP^® is desired (Part #0444, #0445, #0448, #0435, #0438 & #0500).
The Brushless EWP^® can also be controlled using an aftermarket ECU

Designed for Intercooler & Charge Cooling Systems

For performance builds running water-to-air intercoolers, coolant flow stability is critical to reducing intake air temperatures and preventing heat soak.

As a dedicated intercooler pump / charge cooler pump, the EWP^®180:

• Maintains high circulation through restrictive intercooler cores

• Supports large front-mounted heat exchangers

• Delivers consistent flow during sustained boost

• Reduces temperature spikes between pulls

• Improves thermal recovery during track sessions

With 93 L/min at 1.5 bar, the EEWP^®180 significantly outperforms typical small OEM-style intercooler pumps in high-demand applications.

High Performance Cooling & Intercooler Flow

• Open Flow Rate: 180 L/min (47.6 GPM)
• Rated Flow: 93 L/min @ 1.5 bar (15m head)
• Maximum Head Height: 18.4 m (60ft 4.4")
• Maximum Power: 450 W
• Rated Current: 33 A (Max 39 A)

Whether you're running a high-boost turbo engine, LS conversion, endurance race car, off-road vehicle, marine setup, or a high-capacity water-to-air intercooler system, the EWP^®180 provides the flow and pressure capability required to maintain stable coolant and intake air temperatures under load.

For performance builds using charge coolers, this pump ensures rapid coolant circulation between the intercooler core and heat exchanger — helping reduce heat soak and maintain consistent intake air temperatures during repeated pulls, track sessions or sustained boost conditions.

Built for Extreme Conditions

• Operating Voltage Range: 13.5V – 19V
• Ambient Temperature: -40°C to 80°C
• Fluid Temperature: -40°C to 120°C
• IP68 Rated – Fully sealed against dust and water ingress
• EMC Compliant

From extreme cold starts to high ambient under-bonnet temperatures and boosted engine environments, the EWP^®180 is engineered to perform.

Heavy Duty Construction

Manufactured using high-grade materials including:

• ADC12 Aluminium housing
• Stainless steel components
• Silicon carbide mechanical seal
• Nitrile sealing elements
• PPS composite internals

Designed specifically for water and water-based coolant systems, including dedicated intercooler circuits, the EWP^®180 ensures durability and corrosion resistance in demanding cooling environments.
